Brand: Fox ESS
Product code: AEI-00687
Fox ESS 10.0kW T Series 3PH Dual Tracker PV Inverter
- 10 kW
- Three phase
- 1100
- 1100
- 20
Fox ESS T10-M 10.0kW three-phase PV inverter with dual MPPT trackers.
£920.94 inc. VAT
£767.45 exc. VAT
In stock
The Fox ESS T10-M is a 10.0kW three-phase PV inverter from the T Series, designed for residential and small commercial installations. It features two independent MPPT trackers with 1+1 string configuration per tracker, handling dual PV arrays of up to 20kW total across a wide 140–1000V DC input window. Maximum efficiency reaches 98.6% with 97.8% European efficiency, while 99.8% MPPT efficiency maximises power harvest. The wall-mounted enclosure measures 370×450×183.5mm and weighs 17.5kg, with protection class I and overvoltage category III (AC)/II (DC). It includes string current monitoring, DC switch, optional AFCI arc detection, and anti-islanding protection. Remote monitoring integrates through FoxCloud 2.0 app and web portal with AI assistant, and connection options include RS485 and multiple comms ports.
Specifications
Electrical
| Rated Output Power | 10000 W |
|---|---|
| Rated Apparent Power | 10000 VA |
| Max. Apparent Power | 11000 VA |
| Nominal Voltage | 415/240; 400/230; 380/220 V (3L/N/PE) |
| Nominal Frequency | 50/60 ±5 Hz |
| Rated Output Current (Per Phase) | 15.2 A |
| Max. Output Current (Per Phase) | 15.9 A |
| Power Factor | 1 (0.8 leading to 0.8 lagging) |
| THDi | <3% |
DC Input
| Max. Array Power | 20000 W |
|---|---|
| Max. Input Voltage | 1100 V DC |
| Min. Input Voltage | 140 V DC |
| Start-up Input Voltage | 160 V DC |
| Nominal Voltage | 600 V DC |
| MPPT Voltage Range | 140–1000 V DC |
| MPPT Voltage Range (Full Load) | 260–850 V DC |
| Max. Input Current | 20 A per string |
| Max. Short-Circuit Current | 25 A per string |
| Strings per MPPT Tracker | 1+1 |
| Number of MPPT Trackers | 2 |
Performance
| Max. Efficiency | 98.6% |
|---|---|
| European Efficiency | 97.8% |
| MPPT Efficiency | 99.8% |
Protection
| String Current Monitoring | Yes |
|---|---|
| DC Reverse Polarity Protection | Yes |
| Anti-islanding Protection | Yes |
| Output Short Protection | Yes |
| Leakage Current Protection | Yes |
| Insulation Resistance Detection | Yes |
| DC/AC Surge Protection | Type II (DC) / Type II (AC) |
| DC Switch | Yes |
| AFCI Protection | Optional |
Mechanical
| Dimensions (W×H×D) | 370×450×183.5 mm |
|---|---|
| Net Weight | 17.5 kg |
| Installation | Wall-mounted |
| Protective Class | I |
| Overvoltage Category | III (AC), II (DC) |
General
| Operating Temperature Range | −25 to +60 (derating at 45) °C |
|---|---|
| Storage Temperature | −40 to +70 °C |
| Operating Altitude | 3000 m |
| Relative Humidity (Operation/Storage) | 0–100 (No Condensation)% |
| Rated output | 10 kW |
| Phases | Three phase |
| Inverter Mppt Vmax | 1100 |
| Inverter Dc Vmax | 1100 |
| Inverter Mppt Imax | 20 |
Documents and datasheets
Datasheets
T10-M — Datasheet
PDF · 98 kB
