Brand: Fox ESS
Product code: AEI-00688
Fox ESS 12.0kW T Series 3PH Dual Tracker PV Inverter
- 12 kW
- Three phase
- 18
- 140
- 1000
- 1100
Three-phase 12kW solar inverter with dual MPPT and 98.6% efficiency. IP65-rated for outdoor installation.
£994.96 inc. VAT
£829.13 exc. VAT
In stock
The Fox ESS T12-G3 is a three-phase grid-tied inverter designed for small to medium residential and commercial solar installations. Featuring two independent MPPT trackers and transformerless topology, it delivers a maximum efficiency of 98.6% with wide DC voltage flexibility (140-1000V operating range). The IP65-rated aluminium enclosure is engineered for outdoor installation in diverse climates. With natural convection cooling, low standby consumption, and comprehensive monitoring via FoxCloud 2.0, the T12-G3 combines high performance with reliable operation across a wide temperature range.
Specifications
Electrical
| Rated Output Power | 12000 W |
|---|---|
| Max Output Apparent Power | 13200 VA |
| Rated Output Current | 18.2 A |
| Max Output Current | 19.1 A |
| Max Input Voltage | 1100 V DC |
| Rated Input Voltage | 600 V DC |
| Strings per MPPT | 1+1 |
| Power Factor | 1 (adjustable 0.8 leading to 0.8 lagging) |
| THD | <3% |
Performance
| MPPT Efficiency | 99.8% |
|---|---|
| European Efficiency | 97.8% |
| Max Efficiency | 98.6% |
Physical
| Dimensions | 370 x 480 x 183.5 mm |
|---|---|
| Weight | 17 kg |
| Cooling | Natural Convection |
Environmental
| Operating Temperature | -25 to 60 °C |
|---|---|
| Humidity | 0 - 100 (No Condensation)% |
Safety
| Ingress Protection Rating | IP65 |
|---|---|
| Night Consumption | <3 W |
General
| Rated output | 12 kW |
|---|---|
| Phases | Three phase |
| Inverter Dc Max | 18 |
| Inverter Mppt Vmin | 140 |
| Inverter Mppt Vmax | 1000 |
| Inverter Dc Vmax | 1100 |
| Inverter Mppt Imax | 14 |
