Fox ESS 8.0kW T Series 3PH Dual Tracker PV Inverter

8 kW
Three phase
1100
1100
20

Fox ESS T8-M 8.0kW three-phase PV inverter with dual MPPT trackers.

£775.17 inc. VAT

£645.97 exc. VAT

In stock

The Fox ESS T8-M is an 8.0kW three-phase PV inverter from the T Series, designed for small to medium commercial and residential installations. It features two independent MPPT trackers handling arrays up to 16kW across a wide 210–850V DC input window. Maximum efficiency reaches 98.6% with 97.8% European efficiency and 99.8% MPPT efficiency. The wall-mounted enclosure measures 370×450×183.5mm and weighs 17.5kg. It includes string current monitoring, DC switch, anti-islanding protection and optional AFCI arc detection. Remote monitoring is available through FoxCloud 2.0 app and web portal with integrated AI assistant.

Specifications

Electrical

Rated Output Power	8000 W
Rated Apparent Power	8000 VA
Max. Apparent Power	8800 VA
Nominal Voltage	415/240; 400/230; 380/220 V (3L/N/PE)
Rated Output Current (Per Phase)	12.1 A
Max. Output Current (Per Phase)	12.8 A

DC Input

Max. Array Power	16000 W
Max. Input Voltage	1100 V DC
Start-up Input Voltage	160 V DC
MPPT Voltage Range (Full Load)	210–850 V DC
Max. Input Current	20 A per string
Number of MPPT Trackers	2

Performance

Max. Efficiency	98.6%
European Efficiency	97.8%
MPPT Efficiency	99.8%

Protection

String Current Monitoring	Yes
Anti-islanding Protection	Yes
DC Switch	Yes

Mechanical

Dimensions (W×H×D)	370×450×183.5 mm
Net Weight	17.5 kg
Installation	Wall-mounted

General

Operating Temperature Range	−25 to +60 (derating at 45) °C
Storage Temperature	−40 to +70 °C
Relative Humidity	0–100 (No Condensation)%
Rated output	8 kW
Phases	Three phase
Inverter Mppt Vmax	1100
Inverter Dc Vmax	1100
Inverter Mppt Imax	20

Documents and datasheets

Datasheets

T8-M — Datasheet
PDF · 98 kB
Download
