Brand: Fox ESS
Product code: AEB-00237
Fox ESS PQ1 3.7kW with 10kWh (2x EQS 5000) Storage
- 3.7 kW
- 16
- 80
- 550
- 600
- 20
Fox ESS PQ1-3.7 stackable hybrid inverter with 9.84kWh EQ5000 battery storage.
£1,465.82 inc. VAT
£1,221.52 exc. VAT
In stock
Complete residential energy storage system combining Fox ESS's 3.7kW PQ1 stackable all-in-one hybrid inverter with two EQ5000 LFP battery modules for 9.84kWh of usable storage. The inverter accepts up to 16kW of PV input across two MPP trackers with an 80-550V tracking window and delivers 4ms seamless switchover to battery backup. The EQ5000 modules are LFP chemistry with 90% depth of discharge, naturally cooled inverter for under 35dB operation, and full remote monitoring via FoxCloud. System includes the inverter head unit mounted on the battery stack with all cables for plug-and-play installation.
Specifications
Inverter
| Rated Output Power | 3680 W |
|---|---|
| Max. Apparent Power | 3680 VA |
| Rated Output Current | 16.7 A |
| Min. Battery Voltage @ Full AC Load | 78 V |
| Max. Charge/Discharge Current | 50/50 A |
| Switch Time | 4 ms |
| Max. Conversion Efficiency | 97.60% |
| European Efficiency | 97.16% |
Battery
| Nominal Capacity (2-module pack) | 9.84 kWh |
|---|---|
| Chemistry | LFP (LiFePO4) |
| Depth of Discharge | 90% |
Mechanical
| Inverter Dimensions (W x H x D) | 570 x 420 x 380 mm |
|---|---|
| Inverter Net Weight | 35.0 kg |
| Ingress Protection | IP65 |
| Operating Temperature Range | -25 ~ +60 °C |
General
| Rated output | 3.7 kW |
|---|---|
| Inverter Dc Max | 16 |
| Inverter Mppt Vmin | 80 |
| Inverter Mppt Vmax | 550 |
| Inverter Dc Vmax | 600 |
| Inverter Mppt Imax | 20 |
| Inverter Battery Vmin | 80 |
| Inverter Battery Vmax | 500 |
| Battery Chemistry | LFP (LiFePO4) |
Documents and datasheets
Datasheets
PQ1-3.7 with 10kWh EQ5000 Storage — Datasheet
PDF · 496 kB
