Brand: Fox ESS
Product code: AEB-00238
Fox ESS PQ1 3.7kW with 20kWh (4x EQS 5000) Storage
- 3.7 kW
- 16
- 80
- 550
- 600
- 20
Fox ESS PQ1-3.7 stackable hybrid inverter with a four-module EQ5000 battery stack.
£1,487.08 inc. VAT
£1,239.23 exc. VAT
In stock
Extended residential energy storage system combining Fox ESS's 3.7kW PQ1 stackable hybrid inverter with four EQ5000 LFP battery modules in series. The inverter accepts 16kW maximum PV input with two MPPT trackers and provides 4ms seamless switchover to battery backup. The EQ5000 modules offer 90% depth of discharge, connected in series via plug-and-play cabling. Naturally cooled inverter operation keeps noise below 35dB, with remote monitoring through FoxCloud and Ethernet, WiFi, Bluetooth connectivity.
Specifications
Inverter
| Rated Output Power | 3680 W |
|---|---|
| Max. Apparent Power | 3680 VA |
| Rated Output Current | 16.7 A |
| Max. Charge/Discharge Current | 50/50 A |
| Switch Time | 4 ms |
| Max. Conversion Efficiency | 97.60% |
Battery
| Chemistry | LFP (LiFePO4) |
|---|---|
| Depth of Discharge | 90% |
General
| Rated output | 3.7 kW |
|---|---|
| Inverter Dc Max | 16 |
| Inverter Mppt Vmin | 80 |
| Inverter Mppt Vmax | 550 |
| Inverter Dc Vmax | 600 |
| Inverter Mppt Imax | 20 |
| Inverter Battery Vmin | 80 |
| Inverter Battery Vmax | 500 |
| Battery Chemistry | LFP (LiFePO4) |
Documents and datasheets
Datasheets
PQ1-3.7 with 20kWh EQ5000 Storage — Datasheet
PDF · 496 kB
