Brand: Fox ESS
Product code: AEB-00242
Fox ESS PQ1 5kW with 20kWh (4x EQS 5000) Storage
- 5 kW
- 16
- 80
- 550
- 600
- 20
Fox ESS PQ1-5.0 stackable hybrid inverter with a four-module EQ5000 battery stack.
£1,488.24 inc. VAT
£1,240.20 exc. VAT
In stock
Extended residential energy storage system pairing Fox ESS's 5.0kW PQ1 stackable hybrid inverter with four EQ5000 LFP battery modules in series. The 5.0kW inverter accepts 16kW maximum PV input with two independent MPPT trackers and provides 4ms switchover to battery backup. The four EQ5000 modules offer 90% depth of discharge, with all connections made via plug-and-play cabling. System includes naturally cooled inverter, quiet operation under 35dB and remote monitoring through FoxCloud with multiple connectivity options.
Specifications
Inverter
| Rated Output Power | 5000 W |
|---|---|
| Max. Apparent Power | 5500 VA |
| Rated Output Current | 22.7 A |
| Max. Charge/Discharge Current | 50/50 A |
| Switch Time | 4 ms |
| Max. Conversion Efficiency | 97.62% |
Battery
| Chemistry | LFP (LiFePO4) |
|---|
General
| Rated output | 5 kW |
|---|---|
| Inverter Dc Max | 16 |
| Inverter Mppt Vmin | 80 |
| Inverter Mppt Vmax | 550 |
| Inverter Dc Vmax | 600 |
| Inverter Mppt Imax | 20 |
| Inverter Battery Vmin | 80 |
| Inverter Battery Vmax | 500 |
| Battery Chemistry | LFP (LiFePO4) |
Documents and datasheets
Datasheets
PQ1-5.0 with 20kWh EQ5000 Storage — Datasheet
PDF · 496 kB
