SolaX Triple Power 6.0kWh battery stack with BMS
- 5.5
- 204.8
- 6.1
- 6.1
- LFP
SolaX Triple Power T-BAT H 6.0: an MC0600 BMS with two HV10230 LFP modules, 6.1kWh total and 5.5kWh usable at 204.8V.
£2,477.26 inc. VAT
£2,064.39 exc. VAT
Out of stock
The T-BAT H 6.0 is the two-module configuration of SolaX's Triple Power T30 high-voltage battery system: an MC0600 BMS control unit with two HV10230 battery modules built on LFP cells. SolaX rates the stack at 6.1kWh total energy, of which 5.5kWh is usable (tested at 90% depth of discharge), at a rated voltage of 204.8V and an operating range of 180 to 232V. Rated power is 5.1kW and maximum power 6.1kW. The battery communicates with the inverter over RS485 or CAN2.0, is IP65 rated and supports floor mounting. With a BMS-Parallel Box-II G2, up to two towers can be combined. SolaX quotes a cycle life of more than 6,000 cycles at 90% depth of discharge and a 10-year warranty.
Specifications
Battery
| Configuration | MC0600 BMS + 2 x HV10230 battery modules |
|---|---|
| Total energy | 6.1 kWh |
| Rated power | 5.1 kW |
| Max. power | 6.1 kW |
| Operation voltage range | 180-232 V |
| Cycle life (90% DOD) | > 6000 cycles |
Physical
| Net weight, BMS (MC0600) | 7.5 kg |
|---|---|
| Net weight, battery modules (2 x HV10230) | 69 kg |
Protection
| Ingress protection | IP65 |
|---|
General
| Battery Usable | 5.5 |
|---|---|
| Battery Nominal | 204.8 |
| Battery Max Charge | 6.1 |
| Battery Max Discharge | 6.1 |
| Battery Chemistry | LFP |
Documents and datasheets
Datasheets
SolaX Triple Power T-BAT H 6.0 battery stack (MC0600 BMS + 2 x HV10230) — Datasheet
PDF · 831 kB
